| Size | Dimensions(in) | Weight | ||||||
| 100pcs | ||||||||
| (in) | (mm) | A | B | C | D | E | F | (lbs) |
| 1/4 | 6-7 | 2.19 | 1.62 | 1.50 | 0.88 | 0.41 | 0.28 | 6.75 |
| 5/16 | 8 | 2.50 | 1.88 | 1.81 | 1.06 | 0.50 | 0.34 | 11.25 |
| 3/8 | 9-10 | 2.88 | 2.12 | 2.12 | 1.12 | 0.63 | 0.41 | 23.00 |
| 7/16 | 11-12 | 3.25 | 2.38 | 2.38 | 1.25 | 0.72 | 0.47 | 37.00 |
| 1/2-9/16 | 13-15 | 3.62 | 2.75 | 2.75 | 1.50 | 0.89 | 0.59 | 50.00 |
| 5/8 | 16 | 4.25 | 3.25 | 3.12 | 1.75 | 1.00 | 0.66 | 75.00 |
| 3/4 | 18-20 | 5.00 | 3.75 | 3.81 | 2.00 | 1.22 | 0.78 | 147.00 |
| 7/8 | 22 | 5.50 | 4.25 | 4.25 | 2.25 | 1.38 | 0.94 | 175.00 |
| 1 | 24-26 | 6.12 | 4.50 | 4.75 | 2.50 | 1.56 | 1.06 | 280.00 |
| 11/8-11/4 | 28-32 | 7.00 | 5.12 | 5.88 | 2.88 | 1.88 | 1.31 | 400.00 |
| 11/4-13/8 | 32-35 | 9.08 | 6.50 | 6.81 | 3.50 | 2.25 | 1.44 | 820.00 |
| 13/8-11/2 | 35-38 | 9.00 | 6.25 | 7.12 | 3.50 | 2.62 | 1.56 | 1175.00 |
| 1 5/8 | 40 | 11.25 | 8.00 | 8.12 | 4.00 | 3.00 | 1.72 | 1700.00 |
| 1 3/4 | 48-52 | 12.19 | 9.00 | 8.50 | 4.50 | 3.06 | 1.84 | 1775.00 |
| 17/8-2 | 48-52 | 15.12 | 12.00 | 10.38 | 6.00 | 3.38 | 2.09 | 2500.00 |
| 2 1/4 | 56 | 17.50 | 14.00 | 11.88 | 7.00 | 3.88 | 2.38 | 3950.00 |
